Custom selective soldering fixtures
Selective soldering solders specific joints on a PCB without exposing the whole board to a wave — ideal for mixed-technology assemblies. The fixture holds and locates the board so the nozzle or the dip reaches each joint precisely and repeatably. Griftools designs selective fixtures around your board and your machine, whether Ersa, Seho, Inertec or other.
When to choose selective over wave
Selective soldering suits boards with few through-hole joints, tall or heat-sensitive neighbours, or double-sided assemblies where a full wave would be wasteful or risky. Wave soldering is faster for densely through-hole boards at volume. We can advise which fits your line — and build the fixture either way.
Machine compatibility
We design fixtures for the major selective platforms:
Other machines on request — tell us the model and we'll match the fixture to it.
Designed from your Gerber data
Send your Gerber, STEP, DXF, ODB++ or HPGL and information about your machinery. We design for precise nozzle or dip access, board support and repeatable location, then validate with a prototype before series.
- 01Send Gerber / STEP / DXF / ODB++ / HPGL and information about your machinery.
- 02We design for precise nozzle or dip access, support and location.
- 03We validate a prototype on your process.
- 04We move to series — with flexible revisions.
From our own production
Common questions
Which machines do you support?
Ersa, Seho, Inertec and others — tell us the model.
Selective or wave for my board?
We'll advise based on your through-hole count, SMT component positions and volume.
What do you need to quote?
Gerber/STEP/DXF/ODB++/HPGL and the target machine. NDA on request.
Can you handle revisions?
Yes — flexible changes after the prototype.
Have a board and a process?
Send your data and we'll come back with a tailored quote — typically reviewed by a real engineer.
